Applied Acoustics: Dura-Spark UHD Seismic Sound Source
Applied Acoustics: Dura-Spark UHD Seismic Sound Source
Survey Equipment

Applied Acoustics: Dura-Spark UHD Seismic Sound Source

Availability:
Download Data Sheet download download

Add to Basket

The Dura-Spark UHD 240/400 system consists of a negative voltage seismic energy source, the CSP-Nv, a sparker sound source with up to 400 long-life tips, connected by a rugged high voltage cable.

Features

Long life, durable electrodes

Pulse stability

High resolution sub-bottom data, up to 15cms

Compact, lightweight.

Single low loss cable

Specifications

Length: 1893 mm

Height: 372 mm frame, 622 mm including floatation

Width: 650 mm frame, 1280 mm including floatation

Weight: 130 kg (max)

Connector: RMK 1/0 complete with locking collar

Applications

High and Ultra-High Resolution geophysical surveys

Single and multi-channel acquisition

Product Enquiry
