EMCE MR FL Series: Offshore Man-Rider Winch
These winches are dedicated personnel lifting winches supplied with full material traceability. They have passed EC testing for these applications, i.e., both the winches and their technical files are in compliance with the requirements of the EC Machinery Directives.
The winches are designed to the standards issued by the classification bodies and they meet the UK HSE regulations for personnel lifting operations on offshore installations.
Features
Helical shaft mounted gearbox, life lubricated with synthetic oil
Caliper primary brake 180% of WLL
Automatic band brake as secondary drum acting brake 180% of WLL
Pneumatic gear and obit hydraulic motor
Full material traceability (3.1 – EN 10204) on load-bearing parts
Specifications
Power supply: Pneumatic
WLL 1st layer: 200kg
WLL lifting top layer: 150kg
Speed at top layer: 37m/min
Number of layers: 5
Applications
Personnel lifting operations on offshore installations.
