Green Pin®: Lifting Eyes
Unique Group offers the full range of Green Pin Lifting Eyes. The Green Pin® Rotating Hoist Ring is a grade 8 rotating hoist ring. The hoist ring can rotate 360° and pivot 180°. It has ISO metric threads as standard. Other special threads such as UNC are also available. The cylindric head of the screw prevents jamming during rotation of the shackle. The WLL indicated hereunder are given in the worst conditions of use, i.e. 90°. It is necessary to check the free moving of the pivoting shackle. The minimum safety factor is 5:1. The Green Pin® Rotating Hoist Ring is available in a range with a working load limit from 0.4 t. up to 12.5 t. Other lifting eye types are available within the Green Pin range.
Features
Available in Metric and UNC thread options
Sturdy build and coating assure long-term durability
Reliable Green Pin® quality and support
Specifications
Material: Alloy steel, Grade 8, quenched and tempered.
Safety factor: MBL equals 5 x WLL.
Finish: Painted white.
Temp. range: -40°C up to +200°C.
Certification: 2.1 2.2 3.1 MTCa MPIb CE.
Application
Lifting
Mooring
Towing
Fishing
Industrial
