Green Pin®: Mooring Bolts
Green Pin®: Mooring Bolts
Lifting + Mooring

Green Pin®: Mooring Bolts

Availability: ,

Unique Group offers the full range of Green Pin Mooring Bolts. The Green Pin® Mooring Bolt NS9415 T is a grade 8 mooring bolt with a T-shaped end fitting that provides best-in-class quality, guaranteeing absolute security for your mooring system. The mooring bolt’s hot dipped galvanization ensures long-term durability as required by the NS 9415 standard. The mounting depth is indicated by the green colour, which makes the installation of the product much easier and the special type of thread will result in a better fixation of the bolt. What’s more, the mooring bolt NS9415 is certified by DNV in compliance with NYTEK regulation and NS 9415. It is available in a range of minimum breaking load from 40 up to 170 tons.

Features

DNV-certified to NS 9415

Hot dip galvanization assures long-term durability

Better fixation due to special type of thread

Part of Green Pin® aquaculture system

Specifications

Material: high tensile steel, grade 8, quenched and tempered

Finish: Hot dipped galvanized

Temp. range: -20°C up to +200°C

Certification: 2.1 2.2 3.1 MTCa CE DNV NS 9415

Standard: NYTEK regulation and NS 9415

Application

Lifting

Mooring

Towing

Fishing

Industrial
