Green Pin®: Shackles
Unique Group offers the full range of Green Pin Shackles. The Green Pin® Bow Shackle BN is a bow shackle with a safety bolt. The shackle offers a double safety (split pin and safety bolt) which prevents accidental unscrewing of the pin. Long-term durability is assured due to the galvanization of the Green Pin® Bow Shackle BN. Of course, the Green Pin® Bow Shackle BN conforms to a wide range of certifications from class societies such as DNV GL. Other shackle types are available upto and including 1550T SWL wide body.
Unique Group offers the full range of Green Pin Shackles. The Green Pin® Bow Shackle BN is a bow shackle with a safety bolt. The shackle offers a double safety (split pin and safety bolt) which prevents accidental unscrewing of the pin. Long-term durability is assured due to the galvanization of the Green Pin® Bow Shackle BN. Of course, the Green Pin® Bow Shackle BN conforms to a wide range of certifications from class societies such as DNV GL. Other shackle types are available upto and including 1550T SWL wide body.
Features
Market-leading, globally recognised brand
Meets all quality and techncial requirements of clients accorss all industries
Certification and techncial data sets industry standards
DNV, LEEA + IMCA approved brand
Unique production method developed by Green Pin
Specifications
Material: Bow and pin high tensile steel, Grade 6, quenched and tempered
Safety Factor: MBL equals 6 x WLL
Finish: Hot dipped galvanized
Temp. range: -40°C up to +200°C
Certifications: 2.1 2.2 3.1 MTCa DNV 2.7-1a, DNV 2.7-1b DNVGL-ST-0378 CE ABS PDA ABS MA
Standard: EN 13889 and meets performance requirements of US Fed. Spec. RR-C-271, Type IVA, Class 3, Grade A. From 2 t and upward these shackles comply with ASME B30.26
Applications
Lifting
Mooring
Towing
Fishing
Industrial
