Green Pin®: Wire Rope Clips
Unique Group offers the full range of Green Pin Wire Rope Clips. The Green Pin® Wire Rope Clip is a wire rope clip, generally to EN 13411-5 Type B. This wire rope clip is safer to work with as the ribs on the bearing surface of the clip prevent sliding of the wire rope. Furthermore, the wire rope clip is made from high tensile steel, while galvanization ensures its long-term durability. The Green Pin® Wire Rope Clip is available in a range for wire rope diameters of 3 up to 78 mm.
Features
High tensile steel
Ribs prevent sliding of wire rope
Galvanization assures long-term durability
Generally to EN 13411-5 Type B
Specifications
Material: Bridge – drop forged high tensile steel SAE 1045U-bolt: SAE 1015
Finish: Hot dipped galvanizedU-bolt and/or nuts for diameter bow 5, 6, 8 and 10 mm are electro-galvanized
Certification: 2.1
Standard: Generally to EN 13411-5 Type BFormerly US Federal Specification FF-C-450D
Application
Lifting
Mooring
Towing
Fishing
Industrial
